Name: Atmos KC25S 26 kW Coal Gasifier
Brand: Atmos
SKU: 01.12.25
Price: 4258.72 EUR
Availability: InStock

ATMOS KC 25 S Kohlevergaser 26 kW – Festbrennstoffkessel für Braunkohle - GEMA Shop

Highlights

Nennleistung	26,0 kW
Wirkungsgrad	86,0 %
Energieeffizienzklasse	C
Maximale Scheitholzlänge	330 mm
Kesselklasse	Class 5
Rauchrohranschluss	150 mm

Ceramic-lined afterburner chamber for solid fuel operation

Electromechanical control with boiler thermostat and flue gas thermostat

Exhaust fan to support combustion and refueling operation

Thermally insulated steel sheet body with robust boiler construction

Supplied accessories include draft regulator, steel brush, poker, filling valve, and ash container

Atmos KC25S 26 kW Coal Gasifier

by Atmos

SKU 01.12.25

4.258,72 € - 4.258,72 €

4.258,72 €

4.258,72 € - 4.258,72 €

4.258,72 €

Energieeffizienz C

Availability:

Low stock

The Atmos KC25S is a hand-fed coal gasifier with 26 kW output for lignite briquettes and suitable substitute fuels. It combines robust solid fuel technology with a ceramic afterburner chamber, rotating grate mechanism, and electromechanical operation.

Wichtigste Vorteile

Coal gasifier for lignite briquettes with additional use of suitable substitute fuels

Designed for family homes, weekend houses, workshops and comparable properties

Maintenance-oriented design with rotating grate mechanism and ash removal

Fachhandel für Heiztechnik

Technische Beratung für Heiztechnik & Systemkomponenten
Sichere Zahlung
Paket- oder Speditionsversand je nach Produktart

Description

Product Overview & Applications

The Atmos KC25S coal gasifier is a manually fed hot water heating boiler for lignite briquettes with a rated heat output of 26 kW. It is suitable for heating systems in family homes, weekend houses, workshops, and similar properties where a solid fuel boiler with coal gasification technology and the additional use of suitable alternative fuels is required.

Technology & Features

The KC25S operates on the principle of downdraft gasification and uses an induced draft fan to support the combustion process. The boiler body is made of welded steel sheet, the lower secondary combustion chamber is lined with ceramic material, and the rotating grate mechanism aids air distribution and ash removal during operation. Control is via an electromechanical control panel with a thermometer, main switch, boiler thermostat, flue gas thermostat, and safety thermostat.

Everyday Benefits

The combination of a rotating grate mechanism, ceramic combustion chamber, and induced draft fan ensures practical handling in solid fuel operation. The boiler is designed for manual loading and offers a robust technical foundation for users who want a coal gasifier with clear operating logic and a maintenance-oriented design.

System Integration & Compatibility

Professional integration into the heating system with a suitable return temperature protection system must be planned for operation. The manufacturer's documentation specifies a minimum return temperature of 65 °C and a boiler operating temperature in the range of 80 to 90 °C. The hydraulic design, chimney connection, and safety-related integration should be tailored to the building and the existing heating system.

Technical Specifications at a Glance

The key technical data for the Atmos KC25S is summarized here.

Rated Output	26 kW
Fuel	Lignite briquettes, alternative fuel: split logs and wood briquettes
Combustion Technology	Coal gasifier / Downdraft gasification
Efficiency	90.4 %
Energy Efficiency Class	C
Max. Flow Temperature	90 °C
Max. Operating Pressure	2.5 bar
Log Length	330 mm
Boiler Class	5
Draft Requirement	20 Pa
Flue Gas Temperature	177 °C
Flue Pipe Connection	150/152 mm
Safety Heat Exchanger	Cooling loop for overheat protection included
Buffer Tank Recommended	Yes
Height	1185 mm
Width	675 mm
Depth	758 mm
Voltage	230 V
Frequency	50 Hz
Power Consumption	50 W at rated load

Installation

Installation must be planned according to the boiler room, flue gas routing, combustion air supply, and hydraulic integration. The mains connection is 230 V / 50 Hz, the return temperature must be secured via a suitable return temperature protection system, and the chimney connection must be matched to the required draft.

Notes

The KC25S is designed for lignite briquettes as the preferred fuel. Dry split logs and wood briquettes can be used as alternative fuel if the specifications for fuel quality, log length, and moisture content are met. Regular cleaning, sufficient chimney draft, and adherence to the prescribed operating and return temperatures are important for stable operation.

Scope of Delivery

Atmos KC25S coal gasifier
Steel brush with accessories
Poker
Filling valve
Operating and maintenance manual
Honeywell FR 124 draft regulator
Ash container

Technische Daten

Hersteller	Atmos
Produkttyp	Coal gasifier
Modell	KC25S
MPN / Herstellernummer	01.12.25-P
GTIN / EAN	8595183306725
Förderstatus	not eligible for funding
Nennleistung	26.0 kW
Brennstoff	Kohle
Verbrennungstechnik	Coal gasifier
Wirkungsgrad	86.0 %
Energieeffizienzklasse	C
Max. Vorlauftemperatur	65.0 °C
Max. Betriebsdruck	2.5 bar
Max. Scheitholzlänge	330 mm
Kesselklasse	Class 5
Zugbedarf	20 Pa
Abgastemperatur	240 °C
Rauchrohranschluss	150 mm
Empfohlenes Puffervolumen	1500 l
Höhe	1185 mm
Breite	675 mm
Tiefe	758 mm

Dokumente & Downloads

FAQ / Hinweise

Zu diesem Produkt wurden noch keine sauber darstellbaren produktspezifischen Fragen hinterlegt. Unser Fachteam unterstützt dich gerne bei technischen Fragen zur Auswahl, Montage oder Kompatibilität.
